| Display |
| Display diagonal | 190.5 cm (75") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 435 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Panel type | VA |
| Touchscreen technology | PureTouch-IR |
| Number of simultaneous touchpoints | 50 |
| Multi-touch | Yes |
| Number of simultaneous touchpoints (Android) | 40 |
| Native aspect ratio | 16 |
| Response time | 8 ms |
| Contrast ratio (typical) | 5000 |
| Contrast ratio (dynamic) | 5000 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.43 x 0.43 mm |
| Active display area (W x H) | 1650 x 928 mm |
| Display diagonal (metric) | 189.3 cm |
| Horizontal scan range | 30 - 135 kHz |
| Native refresh rate | 60 Hz |
| Haze rate | 25% |
| Surface hardness | 7H |
| Glass thickness | 3 mm |
| Ports & interfaces |
| HDMI ports quantity | 5 |
| DisplayPorts quantity | 1 |
| USB port | Yes |
| HDMI version | 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| DisplayPorts in | 1 |
| DisplayPort version | 2.1 |
| USB ports quantity | 6 |
| USB connector type | USB Type-C |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 100 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | Yes |
| Infrared data port | Yes |
| Remote (IR) input | 1 |
| Audio |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 4 |
| RMS rated power | 54 W |
| Design |
| Product design | Kiosk design |
| Product colour | Black |
| Placement supported | Indoor |
| VESA mounting | Yes |
| Orientation | Horizontal |
| Screen shape | Flat |
| Panel mounting interface | 800 x 400 mm |
| Bezel width (bottom) | 4.1 cm |
| Bezel width (side) | 1.65 cm |
| Bezel width (top) | 1.65 cm |
| Bezel colour | Black |
| Anti-glare screen | Yes |
| Performance |
| Purpose | Universal |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 14 |
| On Screen Display (OSD) languages | Czech, Danish, German, English, Spanish, Finnish, French, Italian, Norwegian, Dutch, Polish, Russian, Swedish |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| Mean time between failures (MTBF) | 50000 h |
| Power |
| Power consumption (typical) | 209 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 197 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Energy efficiency scale | A to G |
| Computer system |
| Computer system | Yes |
| Built-in processor | Yes |
| Processor manufacturer | ARM |
| Processor architecture | ARM Cortex-A76+Cortex-A55 |
| Processor cores | 4 |
| Internal memory | 8 GB |
| On-board graphics card model | ARM Mali-G610 MP4 |
| Internal storage capacity | 64 GB |
| Operating system installed | Android |
| Operating system version | 13 |
| Weight & dimensions |
| Display width | 1709 mm |
| Display depth | 86 mm |
| Display height | 1031 mm |
| Display weight | 51.5 kg |
| Width | 1709 mm |
| Depth | 86 mm |
| Height | 1031 mm |
| Weight | 51.5 kg |
| Packaging data |
| Package width | 1863 mm |
| Package depth | 225 mm |
| Package height | 1148 mm |
| Package weight | 60.8 kg |
| Packaging content |
| Remote control included | Yes |
| Batteries included | Yes |
| Stylus pen | Yes |
| Number of stylus pens | 4 |
| Cables included | AC, USB, HDMI |
| Operational conditions |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Certificates |
| Certification | CB, CE, TÜV-Bauart, EAC, RoHS, WEEE, REACH |
| Network |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi standards | Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b |
| Technical details |
| Sustainability certificates | ErP |
| Warranty period | 5 year(s) |
| Compliance certificates | CB, CE, EAC, REACH, RoHS, TÜV mark, WEEE |
| Other features |
| Quick start guide | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Built-in microphone | Yes |
| Brightness | 450 cd/m² |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Power supply type | Internal |
| Technical details |
| Audio in (mini jack) | Yes |
| Playback media | Y |
| User controls | general settings (input, volume, backlight), display settings (auto brightness, ECO, eye care, paper eye care, picture mode, brightness, contrast, saturation, sharpness, colour temp., advanced settings), audio settings (audio mode, volume, bass, treble, balance, mute), screen settings (pixel shift, auto light, ECR), application settings (network & internet, apps, storage, personal, Google, advanced, administration, system, about) |
